VANQUISH
VANQUISH
STANDING TALL ABOVE THE FIELD
Specifications:
Deck Size - Choice of 52 or 60 inch deck
Standard Deck - Side-discharge
Deck Options - Straight rear-discharge or full mulching
Mow Time - 4.5~7.25hours
Battery Life - 6,000~9,000 mowing hours
Charge Time - 10 Hours
Blade Motors - 3 x 4.0 kW/h
Drive Motors - 2 x 5.0 kW/h
Equivalent HP Rating - 36 HP Petrol
Slope Rating - 20 degrees
Weight - 535 kg
Electronic Deck Control - Yes
Top Speed - 18.5 km/h
Noise Rating - 82 d(B)a
Blade speed - High/Low - 18,000 fpm/16,900 fpm
Full Road Kit - Option
Blower Package - Option
ZTR - Jack - Option
The VANQUISH is the electric stand-on that will vanquish anyone’s need for a gas-powered stand-on mower.
Offered with a 60" or 52" deck with either side or mulching rear discharge and power comparable to a large gas stand on, it is the perfect go-to electric commercial mower for everyday use. Choose between the large 22 kWh battery for all day use or our 14.5 kWh battery for over a half days work.
→ All Day Runtime, up to 8 hours of continuous mowing*
→ 60" or 52" Vortex deck with choice of side discharge or innovative mulching rear discharge
→ Industry exclusive lightweight aluminum chassis and deck for ultra efficient power usage
→ Patented Heavy-Duty Impulse Drive System™ (IDS) provides industry leading performance and reliability
→ Patented battery location for industry leading hillside stability and precision handling
→ Patented Blade Monitoring System for optimal cut quality and efficiency
STANDARD EQUIPMENT
• Aluminum Chassis and Deck
• 11.5 MPH Top Speed
• SmartDeck™ Patented Electronic Cut Height
Adjustment
• Interactive 4" Touch Screen Display
• Blade Speed Monitoring System
• Side Bolstered Thigh Pad
• MICHELIN® TWEEL® Front Caster Wheels
• Phone Holder
• Cup Holder
• Aluminum Chassis and Deck
• 11.5 MPH Top Speed
• SmartDeck™ Patented Electronic Cut Height
Adjustment
• Interactive 4" Touch Screen Display
• Blade Speed Monitoring System
• Side Bolstered Thigh Pad
• MICHELIN® TWEEL® Front Caster Wheels
• Phone Holder
• Cup Holder
ACCESSORIES/OPTIONS
• 14.5 kWh or 22 kWh Battery
• 52" or 60" Side or Mulching Rear Discharge Deck
• MICHELIN® TWEEL® Drive Wheels
• Road Warning Light Kit
• LED Light Kit
• LED Amber Flashing Beacon
• USB Charge Port
• Jack Kit
• 14.5 kWh or 22 kWh Battery
• 52" or 60" Side or Mulching Rear Discharge Deck
• MICHELIN® TWEEL® Drive Wheels
• Road Warning Light Kit
• LED Light Kit
• LED Amber Flashing Beacon
• USB Charge Port
• Jack Kit
